Sidedraft - Model 87

This versatile sidedraft carburetor has been designed to last. Its supply of options allows this model carburetor to satisfy many different engine applications found in most governing systems today.

Application Dimensions

  • Engine Size 100-200 CID
  • Throttle Bore .82, .945, 1.18 inch
  • Choke Bore 1.136, 1.37 inch
  • Venturi Diameter
  • 12-26 mm range
  • Fuel Inlet Fitting
  • 1/8-27 inch pipe thread

Standard Features

  • Multiple Venturi Sizes: allow calibration flexibility
  • Zinc Die Cast Construction
  • Choke and Throttle Levers: may be specified for positioning on either side of carburetor

Optional Features

  • Compact Fuel Shut-Off Solenoid: prevents dieseling
  • Automatic Choke
  • Main Jet Adjustment: provides versatility
  • Back Suction Economizer: supplied for effective part throttle fuel economy
  • Ignition Vacuum Port: provides signal for ignition system

Choke and throttle levers may be specified for positioning on either side of the carburetor. Model 87's multiple venturi sizes allow calibration flexibility.
